STTH1512G
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GEN PURP 1.2KV 15A D2PAK
PDF
/
Buying Options
Total Price: USD $2.42
Unit Price: USD $2.42
≥1 USD $2.42
≥10 USD $1.919808
≥100 USD $1.6456
≥500 USD $1.462754
≥1000 USD $1.252478
≥3000 USD $1.17935
Inventory: 1147
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Number of Pins 3
Diode Element Material SILICON
Technical
Packaging Tube
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Max Operating Temperature 175°C
Min Operating Temperature -65°C
Additional Feature FREE WHEELING DIODE, LOW LEAKAGE CURRENT, SNUBBER DIODE, HIGH RELIABILITY
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 245
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number STTH1512
Pin Count 3
JESD-30 Code R-PSSO-G2
Number of Elements 1
Element Configuration Single
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 15μA @ 1200V
Voltage - Forward (Vf) (Max) @ If 2.1V @ 15A
Case Connection CATHODE
Forward Current 15A
Operating Temperature - Junction 175°C Max
Max Surge Current 150A
Application ULTRA FAST SOFT RECOVERY
Voltage - DC Reverse (Vr) (Max) 1200V
Forward Voltage 2.1V
Max Reverse Voltage (DC) 1.2kV
Average Rectified Current 15A
Number of Phases 1
Reverse Recovery Time 105 ns
Peak Reverse Current 15μA
Max Repetitive Reverse Voltage (Vrrm) 1.2kV
Peak Non-Repetitive Surge Current 200A
Reverse Voltage 1.2kV
Max Forward Surge Current (Ifsm) 200A
Recovery Time 53 ns
Dimensions
Height 4.6mm
Length 10.4mm
Width 9.35mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
