STTH1212G-TR
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GEN PURP 1.2KV 12A D2PAK
PDF
/
Buying Options
Total Price: USD $7.74
Unit Price: USD $7.7425
≥1 USD $7.7425
≥10 USD $6.35265
≥100 USD $6.1541
≥500 USD $5.95555
≥1000 USD $5.757
Inventory: 5003
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Number of Pins 3
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 175°C
Min Operating Temperature -65°C
Additional Feature FREE WHEELING DIODE, LOW LEAKAGE CURRENT, SNUBBER DIODE, HIGH RELIABILITY
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 245
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number STTH1212
Pin Count 3
JESD-30 Code R-PSSO-G2
Qualification Status Not Qualified
Number of Elements 1
Element Configuration Single
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 10μA @ 1200V
Voltage - Forward (Vf) (Max) @ If 2.2V @ 12A
Case Connection CATHODE
Operating Temperature - Junction 175°C Max
Max Surge Current 100A
Application HIGH VOLTAGE ULTRA FAST SOFT RECOVERY
Voltage - DC Reverse (Vr) (Max) 1200V
Forward Voltage 2.2V
Max Reverse Voltage (DC) 1.2kV
Average Rectified Current 12A
Number of Phases 1
Reverse Recovery Time 100 ns
Peak Reverse Current 10μA
Max Repetitive Reverse Voltage (Vrrm) 1.2kV
Peak Non-Repetitive Surge Current 100A
Reverse Voltage 1.2kV
Recovery Time 100 ns
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
