STTH1210FP
RoHS
RoHS compliant
RoHS compliantPackage TO-220-2 Full Pack
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GEN PURP 1KV 12A TO220FP
PDF
/
Inventory: 7794
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Technical
Recovery Time 48 ns
Max Forward Surge Current (Ifsm) 80A
Reverse Voltage 1kV
Peak Non-Repetitive Surge Current 80A
Max Repetitive Reverse Voltage (Vrrm) 1kV
Peak Reverse Current 10μA
Reverse Recovery Time 90 ns
Number of Phases 1
Average Rectified Current 12A
Max Reverse Voltage (DC) 1kV
Forward Voltage 2V
Voltage - DC Reverse (Vr) (Max) 1000V
Application HIGH VOLTAGE ULTRA FAST SOFT RECOVERY
Max Surge Current 80A
Operating Temperature - Junction 175°C Max
Forward Current 12A
Case Connection ISOLATED
Voltage - Forward (Vf) (Max) @ If 2V @ 12A
Output Current 12A
Current - Reverse Leakage @ Vr 10μA @ 1000V
Diode Type Standard
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Single
Number of Elements 1
Qualification Status Not Qualified
Pin Count 3
Base Part Number STTH1210
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Current Rating 12A
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) NOT SPECIFIED
Voltage - Rated DC 1kV
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Additional Feature FREE WHEELING DIODE, LOW LEAKAGE CURRENT, SNUBBER DIODE, HIGH RELIABILITY
Min Operating Temperature -65°C
Max Operating Temperature 175°C
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Packaging Tube
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case TO-220-2 Full Pack
Mounting Type Through Hole
Mount Through Hole
