STTH10R04G
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GEN PURP 400V 10A D2PAK
PDF
/
Inventory: 5537
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Number of Pins 3
Diode Element Material SILICON
Technical
Packaging Tube
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Max Operating Temperature 175°C
Min Operating Temperature -65°C
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number STTH10
Pin Count 2
JESD-30 Code R-PSSO-G2
Qualification Status Not Qualified
Number of Elements 1
Element Configuration Single
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 10μA @ 400V
Voltage - Forward (Vf) (Max) @ If 1.7V @ 10A
Case Connection CATHODE
Operating Temperature - Junction 175°C Max
Max Surge Current 100A
Application ULTRA FAST RECOVERY
Forward Voltage 1.7V
Max Reverse Voltage (DC) 400V
Average Rectified Current 10A
Number of Phases 1
Reverse Recovery Time 40 ns
Peak Reverse Current 10μA
Peak Non-Repetitive Surge Current 100A
Reverse Voltage 400V
Recovery Time 40 ns
Compliance
RoHS Status ROHS3 Compliant
