STTH10LCD06FP
RoHS
RoHS compliant
RoHS compliantPackage TO-220-2 Full Pack
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GEN PURP 600V 10A TO220FP
PDF
/
Buying Options
Total Price: USD $0.86
Unit Price: USD $0.8624
≥1 USD $0.8624
≥10 USD $0.691152
≥100 USD $0.547624
≥500 USD $0.464218
≥1000 USD $0.45914
Inventory: 2230
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Lifecycle Status ACTIVE (Last Updated: 6 months ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-2 Full Pack
Diode Element Material SILICON
Technical
Packaging Tube
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number STTH10
Pin Count 3
JESD-30 Code R-PSFM-T2
Qualification Status Not Qualified
Operating Temperature (Max) 175°C
Number of Elements 1
Configuration SINGLE
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 5μA @ 600V
Voltage - Forward (Vf) (Max) @ If 2V @ 10A
Case Connection ISOLATED
Operating Temperature - Junction 175°C Max
Application HIGH VOLTAGE ULTRA FAST RECOVERY
Voltage - DC Reverse (Vr) (Max) 600V
Max Reverse Voltage (DC) 600V
Average Rectified Current 10A
Number of Phases 1
Reverse Recovery Time 50 ns
JEDEC-95 Code TO-220AC
Non-rep Pk Forward Current-Max 100A
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
