STTH108A
RoHS
RoHS compliant
RoHS compliantPackage DO-214AC, SMA
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GEN PURP 800V 1A SMA
PDF
/
Buying Options
Total Price: USD $0.14
Unit Price: USD $0.13887
≥1 USD $0.13887
≥10 USD $0.13101
≥100 USD $0.1236
≥500 USD $0.1166
≥1000 USD $0.11
≥3000 USD $0.10377
Inventory: 19046
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Lifecycle Status ACTIVE (Last Updated: 6 months ago)
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case DO-214AC, SMA
Number of Pins 2
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Max Operating Temperature 175°C
Min Operating Temperature 0°C
Additional Feature HIGH RELIABILITY, FRE WHEELING DIODE, SNUBBER DIODE
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Voltage - Rated DC 800V
Terminal Position DUAL
Terminal Form C BEND
Peak Reflow Temperature (Cel) 260
Current Rating 1A
Time@Peak Reflow Temperature-Max (s) 10
Base Part Number STTH10
Pin Count 2
Number of Elements 1
Element Configuration Single
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 5μA @ 800V
Output Current 1A
Voltage - Forward (Vf) (Max) @ If 1.65V @ 1A
Forward Current 1A
Operating Temperature - Junction 175°C Max
Max Surge Current 20A
Forward Voltage 1.25V
Max Reverse Voltage (DC) 800V
Average Rectified Current 1A
Reverse Recovery Time 75 ns
Peak Reverse Current 5μA
Max Repetitive Reverse Voltage (Vrrm) 800V
Peak Non-Repetitive Surge Current 20A
Reverse Voltage 800V
Max Forward Surge Current (Ifsm) 20A
Recovery Time 75 ns
Dimensions
Height 2.03mm
Length 4.6mm
Width 2.95mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
