STTA512F
RoHS
/
Package ISOWATT220AC-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GP 1.2KV 5A ISOWATT-220AC
PDF
/
Buying Options
Total Price: USD $0.28
Unit Price: USD $0.27645
≥1 USD $0.27645
≥10 USD $0.22705
≥100 USD $0.2204
≥500 USD $0.2128
≥1000 USD $0.20615
Inventory: 203
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case ISOWATT220AC-3
Number of Pins 220
Diode Element Material SILICON
Technical
Packaging Tube
Series TURBOSWITCH?
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
Max Operating Temperature 150°C
Min Operating Temperature -65°C
Additional Feature FREE WHEELING DIODE, SNUBBER DIODE
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Voltage - Rated DC 1.2kV
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code not_compliant
Current Rating 4A
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number STTA512
Pin Count 2
Reference Standard CECC
JESD-30 Code R-PSFM-T2
Qualification Status Not Qualified
Number of Elements 1
Power Dissipation-Max 13W
Element Configuration Single
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 100μA @ 1200V
Output Current 5A
Voltage - Forward (Vf) (Max) @ If 2.2V @ 5A
Case Connection ISOLATED
Operating Temperature - Junction 150°C Max
Max Surge Current 45A
Application HIGH VOLTAGE ULTRA FAST SOFT RECOVERY
Voltage - DC Reverse (Vr) (Max) 1200V
Max Reverse Voltage (DC) 1.2kV
Average Rectified Current 5A
Number of Phases 1
Reverse Recovery Time 95 ns
Peak Reverse Current 100μA
Reverse Voltage 1.2kV
Recovery Time 95 ns
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
