STTA506B
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GEN PURP 600V 5A DPAK
PDF
/
Inventory: 3602
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Diode Element Material SILICON
Technical
Packaging Tube
Series TURBOSWITCH?
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 150°C
Min Operating Temperature -65°C
Additional Feature SOFT FACTOR IS 0.55, FREE WHEELING DIODE
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Voltage - Rated DC 600V
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Reach Compliance Code not_compliant
Current Rating 5A
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number STTA506
Pin Count 3
JESD-30 Code R-PSSO-G2
Qualification Status Not Qualified
Number of Elements 1
Voltage 600V
Element Configuration Single
Speed Fast Recovery =< 500ns, > 200mA (Io)
Current 5A
Diode Type Standard
Current - Reverse Leakage @ Vr 100μA @ 600V
Power Dissipation 10W
Output Current 5A
Voltage - Forward (Vf) (Max) @ If 1.75V @ 5A
Case Connection CATHODE
Operating Temperature - Junction 150°C Max
Max Surge Current 55A
Application HIGH VOLTAGE ULTRA FAST SOFT RECOVERY
Forward Voltage 1.75V
Max Reverse Voltage (DC) 600V
Average Rectified Current 5A
Number of Phases 1
Reverse Recovery Time 50 ns
Peak Reverse Current 100μA
Peak Non-Repetitive Surge Current 55A
Reverse Voltage 600V
Recovery Time 50 ns
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
