STTA406
RoHS
RoHS compliant
RoHS compliantPackage DO-201AD, Axial
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GEN PURP 600V 4A DO201AD
PDF
/
Inventory: 1780
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case DO-201AD, Axial
Diode Element Material SILICON
Technical
Packaging Tape & Box (TB)
Series TURBOSWITCH?
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Additional Feature FREE WHEELING DIODE, LOW POWER LOSS
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Voltage - Rated DC 600V
Terminal Form WIRE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code not_compliant
Current Rating 4A
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number STTA406
Pin Count 2
JESD-30 Code O-PALF-W2
Qualification Status Not Qualified
Number of Elements 1
Element Configuration Single
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 50μA @ 600V
Output Current 4A
Voltage - Forward (Vf) (Max) @ If 1.75V @ 4A
Case Connection ISOLATED
Operating Temperature - Junction 125°C Max
Max Surge Current 80A
Application EFFICIENCY
Current - Average Rectified (Io) 4A DC
Max Reverse Voltage (DC) 600V
Average Rectified Current 4A
Number of Phases 1
Reverse Recovery Time 55 ns
Peak Reverse Current 50μA
Reverse Voltage 600V
Recovery Time 55 ns
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
