STPSC806G-TR
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 600V 8A D2PAK
PDF
/
Buying Options
Total Price: USD $3.7
Unit Price: USD $3.696
≥1 USD $3.696
≥10 USD $3.10552
Inventory: 112
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Number of Pins 3
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Technical
Peak Non-Repetitive Surge Current 120A
Capacitance @ Vr, F 450pF @ 0V 1MHz
Max Repetitive Reverse Voltage (Vrrm) 600V
Peak Reverse Current 100nA
Reverse Recovery Time 0ns
Number of Phases 1
Average Rectified Current 8A
Max Reverse Voltage (DC) 600V
Forward Voltage 1.7V
Application POWER
Output Current-Max 8A
Max Surge Current 30A
Operating Temperature - Junction -40°C~175°C
Max Reverse Leakage Current 100μA
Forward Current 8A
Case Connection CATHODE
Voltage - Forward (Vf) (Max) @ If 1.7V @ 8A
Current - Reverse Leakage @ Vr 100μA @ 600V
Diode Type Silicon Carbide Schottky
Speed No Recovery Time > 500mA (Io)
Element Configuration Single
Number of Elements 1
JESD-30 Code R-PSSO-G2
Pin Count 3
Base Part Number STPSC806
Peak Reflow Temperature (Cel) 245
Terminal Form GULL WING
Subcategory Rectifier Diodes
Min Operating Temperature -40°C
Max Operating Temperature 175°C
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Packaging Tape & Reel (TR)
