STPSC6H065B-TR
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 650V 6A DPAK
PDF
/
Buying Options
Total Price: USD $2.34
Unit Price: USD $2.3408
≥1 USD $2.3408
≥10 USD $1.9448
≥100 USD $1.548272
≥500 USD $1.310038
≥1000 USD $1.111554
Inventory: 4260
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Technical
Peak Non-Repetitive Surge Current 400A
Capacitance @ Vr, F 300pF @ 0V 1MHz
Max Repetitive Reverse Voltage (Vrrm) 650V
Peak Reverse Current 60μA
Reverse Recovery Time 0ns
Number of Phases 1
Average Rectified Current 6A
Max Reverse Voltage (DC) 650V
Application POWER
Output Current-Max 6A
Max Surge Current 60A
Operating Temperature - Junction -40°C~175°C
Max Reverse Leakage Current 60μA
Forward Current 6A
Case Connection CATHODE
Voltage - Forward (Vf) (Max) @ If 1.75V @ 6A
Current - Reverse Leakage @ Vr 60μA @ 650V
Diode Type Silicon Carbide Schottky
Speed No Recovery Time > 500mA (Io)
Element Configuration Single
Number of Elements 1
JESD-30 Code R-PSSO-G2
Base Part Number STPSC6
Terminal Form GULL WING
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Min Operating Temperature -40°C
Max Operating Temperature 175°C
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Packaging Tape & Reel (TR)
Physical
Number of Pins 3
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 14 Weeks
