STPSC20H12DY
RoHS
RoHS compliant
RoHS compliantPackage TO-220-2
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 1.2KV 20A TO220AC
PDF
/
Buying Options
Total Price: USD $10.34
Unit Price: USD $10.34
≥1 USD $10.34
≥10 USD $8.257216
≥100 USD $7.387952
≥500 USD $6.518811
Inventory: 999
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mounting Type Through Hole
Package / Case TO-220-2
Surface Mount NO
Technical
Packaging Tube
Series Automotive, AEC-Q101, ECOPACK?2
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Terminal Position SINGLE
Base Part Number STPSC20
JESD-30 Code R-PSFM-T2
Operating Temperature (Max) 175°C
Number of Elements 1
Configuration SINGLE
Speed No Recovery Time > 500mA (Io)
Diode Type Silicon Carbide Schottky
Current - Reverse Leakage @ Vr 120μA @ 1200V
Voltage - Forward (Vf) (Max) @ If 1.5V @ 20A
Case Connection CATHODE
Forward Current 38A
Operating Temperature - Junction -40°C~175°C
Output Current-Max 20A
Application POWER
Voltage - DC Reverse (Vr) (Max) 1200V
Current - Average Rectified (Io) 20A
Number of Phases 1
Reverse Recovery Time 0ns
Rep Pk Reverse Voltage-Max 1200V
Capacitance @ Vr, F 1650pF @ 0V 1MHz
Reverse Current-Max 120μA
Reverse Test Voltage 1200V
Compliance
RoHS Status ROHS3 Compliant
