STPSC20065D
RoHS
RoHS compliant
RoHS compliantPackage TO-220-2
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
STMICROELECTRONICS STPSC20065D Silicon Carbide Schottky Diode, Single, 650 V, 20 A, 62 nC, TO-220ACNew
PDF
/
Buying Options
Total Price: USD $5.14
Unit Price: USD $5.1392
≥1 USD $5.1392
≥10 USD $4.31552
≥100 USD $3.491048
≥500 USD $3.103126
≥1000 USD $2.657046
≥3000 USD $2.501893
Inventory: 991
Minimum: 1
-
+
Technical Details
Technical
Reverse Current-Max 300μA
Capacitance @ Vr, F 1250pF @ 0V 1MHz
Max Repetitive Reverse Voltage (Vrrm) 650V
Reverse Recovery Time 0ns
Number of Phases 1
Voltage - DC Reverse (Vr) (Max) 650V
Application HIGH VOLTAGE POWER
Operating Temperature - Junction -40°C~175°C
Forward Current 20A
Case Connection CATHODE
Voltage - Forward (Vf) (Max) @ If 1.45V @ 20A
Current - Reverse Leakage @ Vr 300μA @ 650V
Diode Type Silicon Carbide Schottky
Speed No Recovery Time > 500mA (Io)
Element Configuration Single
Number of Elements 1
Operating Temperature (Max) 175°C
Base Part Number STPSC2006
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Additional Feature FREE WHEELING DIODE
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series ECOPACK?2
Packaging Tube
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Physical
Number of Pins 2
Surface Mount NO
Package / Case TO-220-2
Mounting Type Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 14 Weeks
