STPSC15H12D
RoHS
RoHS compliant
RoHS compliantPackage TO-220-2
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
STMicroelectronics 1200V 15A, SiC Schottky Diode, 2-Pin TO-220AC STPSC15H12D
PDF
/
Buying Options
Total Price: USD $6.29
Unit Price: USD $6.292
≥1 USD $6.292
≥10 USD $5.024448
≥100 USD $4.495568
≥500 USD $3.96667
≥1000 USD $3.570002
≥3000 USD $3.345223
Inventory: 2951
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Lifecycle Status ACTIVE (Last Updated: 6 months ago)
Physical
Mounting Type Through Hole
Package / Case TO-220-2
Surface Mount NO
Technical
Packaging Tube
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number STPSC15
JESD-30 Code R-PSFM-T2
Operating Temperature (Max) 175°C
Number of Elements 1
Configuration SINGLE
Speed No Recovery Time > 500mA (Io)
Diode Type Silicon Carbide Schottky
Current - Reverse Leakage @ Vr 90μA @ 1200V
Voltage - Forward (Vf) (Max) @ If 1.5V @ 15A
Case Connection CATHODE
Forward Current 15A
Operating Temperature - Junction -40°C~175°C
Application POWER
Voltage - DC Reverse (Vr) (Max) 1200V
Number of Phases 1
Reverse Recovery Time 0ns
Rep Pk Reverse Voltage-Max 1200V
JEDEC-95 Code TO-220AC
Capacitance @ Vr, F 1200pF @ 0V 1MHz
Reverse Current-Max 90μA
Compliance
RoHS Status ROHS3 Compliant
