STPSC10H12WL
RoHS
RoHS compliant
RoHS compliantPackage DO-247-2 (Straight Leads)
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 1.2KV 10A DO247
PDF
/
Buying Options
Total Price: USD $4.51
Unit Price: USD $4.5056
≥1 USD $4.5056
≥10 USD $3.57133
≥100 USD $3.06115
≥500 USD $2.721013
≥1000 USD $2.329862
≥3000 USD $2.193814
Inventory: 429
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Reverse Current-Max 60μA
Capacitance @ Vr, F 725pF @ 0V 1MHz
Rep Pk Reverse Voltage-Max 1200V
Reverse Recovery Time 0ns
Number of Phases 1
Voltage - DC Reverse (Vr) (Max) 1200V
Application POWER
Operating Temperature - Junction -40°C~175°C
Forward Current 10A
Case Connection CATHODE
Voltage - Forward (Vf) (Max) @ If 1.5V @ 10A
Current - Reverse Leakage @ Vr 60μA @ 1200V
Diode Type Silicon Carbide Schottky
Speed No Recovery Time > 500mA (Io)
Configuration SINGLE
Number of Elements 1
Operating Temperature (Max) 175°C
JESD-30 Code R-PSFM-T2
Base Part Number STPSC10
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series ECOPACK?2
Packaging Tube
Physical
Surface Mount NO
Package / Case DO-247-2 (Straight Leads)
Mounting Type Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 14 Weeks
