STPS8H100FP
RoHS
RoHS compliant
RoHS compliantPackage TO-220-2 Full Pack, Isolated Tab
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 100V 8A TO220FPAC
PDF
/
Buying Options
Total Price: USD $0.81
Unit Price: USD $0.8096
≥1 USD $0.8096
≥10 USD $0.669504
≥100 USD $0.485936
≥500 USD $0.406032
≥1000 USD $0.345567
≥3000 USD $0.307771
Inventory: 743
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-2 Full Pack, Isolated Tab
Number of Pins 2
Diode Element Material SILICON
Technical
Packaging Tube
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Max Operating Temperature 175°C
Min Operating Temperature -65°C
Additional Feature LOW LEAKAGE CURRENT
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Base Part Number STPS8H
Pin Count 2
Number of Elements 1
Element Configuration Single
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 4.5μA @ 100V
Voltage - Forward (Vf) (Max) @ If 710mV @ 8A
Forward Current 8A
Max Reverse Leakage Current 4.5μA
Operating Temperature - Junction 175°C Max
Max Surge Current 250A
Output Current-Max 8A
Application HIGH VOLTAGE POWER
Forward Voltage 810mV
Max Reverse Voltage (DC) 100V
Average Rectified Current 8A
Number of Phases 1
Peak Reverse Current 4.5μA
Max Repetitive Reverse Voltage (Vrrm) 100V
Peak Non-Repetitive Surge Current 250A
Dimensions
Height 16.4mm
Length 10.4mm
Width 4.6mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
