STPS5L60SY
RoHS
RoHS compliant
RoHS compliantPackage DO-214AB, SMC
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 60V 5A SMC
PDF
/
Buying Options
Total Price: USD $0.6
Unit Price: USD $0.5984
≥1 USD $0.5984
≥10 USD $0.51744
≥100 USD $0.357984
≥500 USD $0.299094
≥1000 USD $0.254549
Inventory: 3448
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case DO-214AB, SMC
Number of Pins 2
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
Series Q Automotive
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Max Operating Temperature 150°C
Min Operating Temperature -40°C
Subcategory Rectifier Diodes
Terminal Position DUAL
Terminal Form C BEND
Reach Compliance Code not_compliant
Base Part Number STPS5
Reference Standard AEC-Q101
Number of Elements 1
Element Configuration Single
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 220μA @ 60V
Voltage - Forward (Vf) (Max) @ If 520mV @ 5A
Forward Current 5A
Max Reverse Leakage Current 100mA
Operating Temperature - Junction -40°C~150°C
Max Surge Current 150A
Output Current-Max 5A
Application EFFICIENCY
Forward Voltage 520mV
Max Reverse Voltage (DC) 60V
Average Rectified Current 5A
Number of Phases 1
Peak Non-Repetitive Surge Current 150A
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
