STPS5L60S
RoHS
RoHS compliant
RoHS compliantPackage DO-214AB, SMC
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 60V 5A SMC
PDF
/
Buying Options
Total Price: USD $0.55
Unit Price: USD $0.5544
≥1 USD $0.5544
≥10 USD $0.46992
≥100 USD $0.326568
≥500 USD $0.254936
≥1000 USD $0.207222
Inventory: 25579
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 6.25mm
Length 7.15mm
Height 2.65mm
Technical
Max Junction Temperature (Tj) 150°C
Max Forward Surge Current (Ifsm) 150A
Peak Non-Repetitive Surge Current 150A
Max Repetitive Reverse Voltage (Vrrm) 60V
Peak Reverse Current 220μA
Number of Phases 1
Average Rectified Current 5A
Max Reverse Voltage (DC) 60V
Forward Voltage 520mV
Application EFFICIENCY
Output Current-Max 5A
Max Surge Current 150A
Operating Temperature - Junction 150°C Max
Max Reverse Leakage Current 220μA
Forward Current 5A
Voltage - Forward (Vf) (Max) @ If 520mV @ 5A
Current - Reverse Leakage @ Vr 220μA @ 60V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Single
Number of Elements 1
Pin Count 2
Base Part Number STPS5
Time@Peak Reflow Temperature-Max (s) 10
Peak Reflow Temperature (Cel) 260
Terminal Form C BEND
Terminal Position DUAL
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Min Operating Temperature -65°C
Max Operating Temperature 150°C
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-214AB, SMC
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 months ago)
Factory Lead Time 11 Weeks
