STPS5L25B-TR
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 25V 5A DPAK
PDF
/
Buying Options
Total Price: USD $0.73
Unit Price: USD $0.7304
≥1 USD $0.7304
≥10 USD $0.63184
≥100 USD $0.43736
≥500 USD $0.365429
≥1000 USD $0.31101
Inventory: 1648
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 6.2mm
Length 6.6mm
Height 2.4mm
Technical
Max Forward Surge Current (Ifsm) 75A
Peak Non-Repetitive Surge Current 75A
Max Repetitive Reverse Voltage (Vrrm) 25V
Peak Reverse Current 350μA
Number of Phases 1
Average Rectified Current 5A
Max Reverse Voltage (DC) 25V
Forward Voltage 590mV
Application EFFICIENCY
Max Surge Current 75A
Operating Temperature - Junction 150°C Max
Max Reverse Leakage Current 350μA
Forward Current 5A
Case Connection CATHODE
Voltage - Forward (Vf) (Max) @ If 470mV @ 5A
Output Current 5A
Current - Reverse Leakage @ Vr 350μA @ 25V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Single
Polarity Standard
Number of Elements 1
JESD-30 Code R-PSSO-G2
Base Part Number STPS5
Time@Peak Reflow Temperature-Max (s) 30
Current Rating 5A
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Voltage - Rated DC 25V
Subcategory Rectifier Diodes
Additional Feature AVALANCHE RATED
Min Operating Temperature -65°C
Max Operating Temperature 150°C
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Number of Pins 4
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 11 Weeks
