STPS5H100AF
RoHS
RoHS compliant
RoHS compliantPackage SOD-128
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 100V 5A SOD128
PDF
/
Buying Options
Total Price: USD $0.53
Unit Price: USD $0.528
≥1 USD $0.528
≥10 USD $0.4488
≥100 USD $0.31196
≥500 USD $0.243584
≥1000 USD $0.197982
Inventory: 1713
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Physical
Mounting Type Surface Mount
Package / Case SOD-128
Surface Mount YES
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Additional Feature LOW LEAKAGE CURRENT
Terminal Position DUAL
Terminal Form FLAT
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number STPS5
JESD-30 Code R-PDSO-F2
Operating Temperature (Max) 175°C
Number of Elements 1
Configuration SINGLE
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 3.5μA @ 100V
Voltage - Forward (Vf) (Max) @ If 760mV @ 5A
Forward Current 5A
Operating Temperature - Junction 175°C Max
Application HIGH VOLTAGE POWER
Voltage - DC Reverse (Vr) (Max) 100V
Number of Phases 1
Rep Pk Reverse Voltage-Max 100V
Reverse Current-Max 3.5μA
Compliance
RoHS Status ROHS3 Compliant
