STPS4S200UF
RoHS
RoHS compliant
RoHS compliantPackage DO-221AA, SMB Flat Leads
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 200V 4A SMBFLAT
PDF
/
Buying Options
Total Price: USD $0.42
Unit Price: USD $0.4224
≥1 USD $0.4224
≥10 USD $0.36432
≥100 USD $0.253264
≥500 USD $0.197754
≥1000 USD $0.160732
≥3000 USD $0.143686
Inventory: 20414
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Reverse Current-Max 5μA
Number of Phases 1
Average Rectified Current 4A
Max Reverse Voltage (DC) 200V
Application POWER
Operating Temperature - Junction -40°C~175°C
Forward Current 4A
Voltage - Forward (Vf) (Max) @ If 870mV @ 4A
Current - Reverse Leakage @ Vr 5μA @ 200V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Configuration SINGLE
Number of Elements 1
Operating Temperature (Max) 175°C
JESD-30 Code R-PDSO-F2
Base Part Number STPS4
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Additional Feature FREE WHEELING DIODE, LOW LEAKAGE CURRENT
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series ECOPACK?
Packaging Cut Tape (CT)
Physical
Diode Element Material SILICON
Package / Case DO-221AA, SMB Flat Leads
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 8 Weeks
