STPS3L60U
RoHS
RoHS compliant
RoHS compliantPackage DO-214AA, SMB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 60V 3A SMB
PDF
/
Buying Options
Total Price: USD $0.24
Unit Price: USD $0.24068
≥1 USD $0.24068
≥10 USD $0.22706
≥100 USD $0.21421
≥500 USD $0.20208
≥1000 USD $0.19064
≥3000 USD $0.17985
Inventory: 58198
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 3.95mm
Length 4.6mm
Height 2.65mm
Technical
Max Junction Temperature (Tj) 150°C
Max Forward Surge Current (Ifsm) 100A
Peak Non-Repetitive Surge Current 100A
Max Repetitive Reverse Voltage (Vrrm) 60V
Peak Reverse Current 150μA
Number of Phases 1
Average Rectified Current 3A
Max Reverse Voltage (DC) 60V
Forward Voltage 620mV
Application POWER
Max Surge Current 100A
Operating Temperature - Junction 150°C Max
Max Reverse Leakage Current 150μA
Forward Current 3A
Voltage - Forward (Vf) (Max) @ If 620mV @ 3A
Output Current 3A
Current - Reverse Leakage @ Vr 150μA @ 60V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Single
Polarity Standard
Number of Elements 1
Pin Count 2
Base Part Number STPS3L
Time@Peak Reflow Temperature-Max (s) 30
Current Rating 3A
Peak Reflow Temperature (Cel) 260
Terminal Form C BEND
Terminal Position DUAL
Voltage - Rated DC 60V
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Additional Feature AVALANCHE CAPABILITY
Min Operating Temperature -65°C
Max Operating Temperature 150°C
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-214AA, SMB
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 11 Weeks
