STPS3L60QRL
RoHS
RoHS compliant
RoHS compliantPackage DO-204AC, DO-15, Axial
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
Diode Schottky 60V 3A 2-Pin DO-15 T/R
PDF
/
Buying Options
Total Price: USD $0.39
Unit Price: USD $0.3872
≥1 USD $0.3872
Inventory: 1562
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case DO-204AC, DO-15, Axial
Number of Pins 2
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Max Operating Temperature 150°C
Min Operating Temperature -65°C
Additional Feature AVALANCHE CAPABILITY
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Voltage - Rated DC 60V
Terminal Form WIRE
Current Rating 3A
Base Part Number STPS3L
Pin Count 2
Number of Elements 1
Polarity Standard
Element Configuration Single
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 60μA @ 60V
Output Current 3A
Voltage - Forward (Vf) (Max) @ If 620mV @ 3A
Case Connection ISOLATED
Forward Current 3A
Max Reverse Leakage Current 150μA
Operating Temperature - Junction 150°C Max
Max Surge Current 100A
Application POWER
Forward Voltage 790mV
Max Reverse Voltage (DC) 60V
Average Rectified Current 3A
Number of Phases 1
Peak Reverse Current 150μA
Max Repetitive Reverse Voltage (Vrrm) 60V
Peak Non-Repetitive Surge Current 100A
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
