STPS3150
RoHS
RoHS compliant
RoHS compliantPackage DO-201AD, Axial
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 150V 3A DO201AD
PDF
/
Buying Options
Total Price: USD $0.21
Unit Price: USD $0.20805
≥1 USD $0.20805
≥10 USD $0.171
≥100 USD $0.1653
≥500 USD $0.16055
≥1000 USD $0.15485
Inventory: 1886
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case DO-201AD, Axial
Number of Pins 2
Diode Element Material SILICON
Technical
Packaging Tape & Box (TB)
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Max Operating Temperature 175°C
Min Operating Temperature -65°C
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Voltage - Rated DC 150V
Terminal Form WIRE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code not_compliant
Current Rating 3A
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number STPS3150
Pin Count 2
Qualification Status Not Qualified
Number of Elements 1
Polarity Standard
Element Configuration Single
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 2μA @ 150V
Output Current 3A
Voltage - Forward (Vf) (Max) @ If 820mV @ 3A
Case Connection ISOLATED
Max Reverse Leakage Current 2μA
Operating Temperature - Junction 175°C Max
Max Surge Current 150A
Application EFFICIENCY
Forward Voltage 890mV
Max Reverse Voltage (DC) 150V
Average Rectified Current 3A
Number of Phases 1
Peak Non-Repetitive Surge Current 100A
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
