STPS30SM100SFP
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Full Pack
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 100V 30A TO220FP
PDF
/
Buying Options
Total Price: USD $14.48
Unit Price: USD $14.478
≥1 USD $14.478
≥10 USD $11.8788
≥100 USD $11.5083
≥500 USD $11.13685
≥1000 USD $10.7654
Inventory: 1156
Minimum: 1
-
+
Technical Details
Technical
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 3
ECCN Code EAR99
Max Operating Temperature 150°C
Min Operating Temperature -65°C
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Terminal Position SINGLE
Base Part Number STPS30
Pin Count 3
Number of Elements 1
Element Configuration Common Anode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 45μA @ 100V
Voltage - Forward (Vf) (Max) @ If 870mV @ 30A
Case Connection ISOLATED
Forward Current 30A
Max Reverse Leakage Current 45μA
Operating Temperature - Junction 150°C Max
Max Surge Current 530A
Application EFFICIENCY
Forward Voltage 870mV
Max Reverse Voltage (DC) 100V
Average Rectified Current 30A
Number of Phases 1
Peak Reverse Current 45μA
Max Repetitive Reverse Voltage (Vrrm) 100V
JEDEC-95 Code TO-220AB
Peak Non-Repetitive Surge Current 530A
Max Forward Surge Current (Ifsm) 530A
Packaging Tube
Physical
Diode Element Material SILICON
Number of Pins 3
Package / Case TO-220-3 Full Pack
Mounting Type Through Hole
Mount Through Hole
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
