STPS30120DJF-TR
RoHS
RoHS compliant
RoHS compliantPackage 8-PowerVDFN
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 120V 30A POWRFLAT
PDF
/
Buying Options
Total Price: USD $1.14
Unit Price: USD $1.144
≥1 USD $1.144
≥10 USD $0.93632
≥100 USD $0.727936
≥500 USD $0.617003
≥1000 USD $0.502621
Inventory: 22711
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-PowerVDFN
Number of Pins 8
Diode Element Material SILICON
Technical
Packaging Cut Tape (CT)
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Max Operating Temperature 150°C
Min Operating Temperature -65°C
Additional Feature FREE WHEELING DIODE
Terminal Position DUAL
Terminal Form FLAT
Peak Reflow Temperature (Cel) 260
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number STPS30120
Pin Count 8
JESD-30 Code R-PDSO-F5
Number of Elements 1
Element Configuration Common Anode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 35μA @ 120V
Voltage - Forward (Vf) (Max) @ If 920mV @ 30A
Case Connection CATHODE
Forward Current 30A
Operating Temperature - Junction 150°C Max
Application FAST RECOVERY POWER
Forward Voltage 920mV
Max Reverse Voltage (DC) 120V
Average Rectified Current 30A
Number of Phases 1
Peak Reverse Current 35μA
Max Repetitive Reverse Voltage (Vrrm) 120V
Peak Non-Repetitive Surge Current 200A
Max Forward Surge Current (Ifsm) 200A
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
