STPS2L60
RoHS
RoHS compliant
RoHS compliantPackage DO-204AL, DO-41, Axial
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 60V 2A DO41
PDF
/
Buying Options
Total Price: USD $0.42
Unit Price: USD $0.4224
≥1 USD $0.4224
≥10 USD $0.32824
≥100 USD $0.196944
≥500 USD $0.182389
≥1000 USD $0.124018
Inventory: 1547
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case DO-204AL, DO-41, Axial
Number of Pins 2
Weight 113.398093g
Diode Element Material SILICON
Technical
Packaging Cut Tape (CT)
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Max Operating Temperature 150°C
Min Operating Temperature -65°C
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Voltage - Rated DC 60V
Terminal Form WIRE
Current Rating 2A
Base Part Number STPS2L60
Pin Count 2
Number of Elements 1
Polarity Standard
Element Configuration Single
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 100μA @ 60V
Output Current 2A
Voltage - Forward (Vf) (Max) @ If 600mV @ 2A
Case Connection ISOLATED
Forward Current 2A
Max Reverse Leakage Current 100μA
Operating Temperature - Junction 150°C Max
Max Surge Current 75A
Application POWER
Forward Voltage 600mV
Max Reverse Voltage (DC) 60V
Average Rectified Current 2A
Number of Phases 1
Peak Reverse Current 100μA
Max Repetitive Reverse Voltage (Vrrm) 60V
Peak Non-Repetitive Surge Current 75A
Max Forward Surge Current (Ifsm) 75A
Dimensions
Diameter 2.7 mm
Height 6.35mm
Length 5.2mm
Width 6.35mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
