STPS20SM120ST
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 170V 1A TO220AB
PDF
/
Buying Options
Total Price: USD $0.97
Unit Price: USD $0.968
≥1 USD $0.968
≥10 USD $0.780736
≥100 USD $0.618728
≥500 USD $0.524462
≥1000 USD $0.427222
≥3000 USD $0.402178
Inventory: 1229
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3
Diode Element Material SILICON
Technical
Packaging Tube
Series ECOPACK?2
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number STPS20
JESD-30 Code R-PSFM-T3
Operating Temperature (Max) 150°C
Number of Elements 1
Configuration SINGLE
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 210μA @ 120V
Voltage - Forward (Vf) (Max) @ If 890mV @ 20A
Case Connection CATHODE
Operating Temperature - Junction 150°C Max
Output Current-Max 20A
Application EFFICIENCY
Voltage - DC Reverse (Vr) (Max) 120V
Current - Average Rectified (Io) 20A
Max Reverse Voltage (DC) 170V
Average Rectified Current 1A
Number of Phases 1
Non-rep Pk Forward Current-Max 220A
Reverse Current-Max 210μA
Compliance
RoHS Status ROHS3 Compliant
