STPS20M60ST
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 60V 20A TO220AB
PDF
/
Inventory: 8260
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3
Number of Pins 3
Diode Element Material SILICON
Technical
Packaging Tube
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Max Operating Temperature 150°C
Min Operating Temperature -65°C
Subcategory Rectifier Diodes
Base Part Number STPS20
Pin Count 3
Number of Elements 1
Element Configuration Single
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 125μA @ 60V
Voltage - Forward (Vf) (Max) @ If 565mV @ 20A
Case Connection CATHODE
Forward Current 20A
Max Reverse Leakage Current 125μA
Operating Temperature - Junction 150°C Max
Max Surge Current 600A
Application POWER
Forward Voltage 565mV
Max Reverse Voltage (DC) 60V
Average Rectified Current 20A
Number of Phases 1
Peak Reverse Current 125μA
Max Repetitive Reverse Voltage (Vrrm) 60V
JEDEC-95 Code TO-220AB
Peak Non-Repetitive Surge Current 600A
Max Forward Surge Current (Ifsm) 600A
Dimensions
Height 15.75mm
Length 10.4mm
Width 4.6mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
