STPS20LCD200CBTR
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 200V DPAK
PDF
/
Inventory: 3216
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Reverse Current-Max 5μA
Non-rep Pk Forward Current-Max 125A
Rep Pk Reverse Voltage-Max 200V
Number of Phases 1
Current - Average Rectified (Io) 10A
Voltage - DC Reverse (Vr) (Max) 200V
Application EFFICIENCY
Operating Temperature - Junction 175°C Max
Case Connection CATHODE
Voltage - Forward (Vf) (Max) @ If 950mV @ 10A
Current - Reverse Leakage @ Vr 5μA @ 200V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Configuration COMMON CATHODE, 2 ELEMENTS
Number of Elements 2
Operating Temperature (Max) 175°C
JESD-30 Code R-PSSO-G2
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position SINGLE
Additional Feature LOW LEAKAGE CURRENT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Surface Mount YES
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type Surface Mount
