STPS20L15G-TR
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 15V 20A D2PAK
PDF
/
Buying Options
Total Price: USD $3.22
Unit Price: USD $3.2224
≥1 USD $3.2224
≥10 USD $2.64385
≥100 USD $2.5612
≥500 USD $2.47855
≥1000 USD $2.3959
Inventory: 49567
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Number of Pins 3
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 125°C
Min Operating Temperature -65°C
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Voltage - Rated DC 15V
Terminal Form GULL WING
Current Rating 20A
Base Part Number STPS20
Pin Count 2
JESD-30 Code R-PSSO-G2
Number of Elements 1
Polarity Standard
Element Configuration Single
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 6mA @ 15V
Output Current 20A
Voltage - Forward (Vf) (Max) @ If 410mV @ 19A
Case Connection CATHODE
Forward Current 20A
Max Reverse Leakage Current 6mA
Operating Temperature - Junction 125°C Max
Max Surge Current 310A
Application POWER
Forward Voltage 520mV
Max Reverse Voltage (DC) 15V
Average Rectified Current 20A
Number of Phases 1
Peak Reverse Current 6mA
Max Repetitive Reverse Voltage (Vrrm) 15V
Peak Non-Repetitive Surge Current 310A
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
