STPS1L40AY
RoHS
RoHS compliant
RoHS compliantPackage DO-214AC, SMA
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 40V 1A SMA
PDF
/
Buying Options
Total Price: USD $0.39
Unit Price: USD $0.3872
≥1 USD $0.3872
≥10 USD $0.27632
≥100 USD $0.13948
≥500 USD $0.12357
≥1000 USD $0.096166
≥3000 USD $0.086073
Inventory: 8712
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case DO-214AC, SMA
Number of Pins 2
Diode Element Material SILICON
Technical
Packaging Cut Tape (CT)
Series Q Automotive
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Max Operating Temperature 150°C
Min Operating Temperature -40°C
Additional Feature FREE WHEELING DIODE
Subcategory Rectifier Diodes
Terminal Position DUAL
Terminal Form C BEND
Base Part Number STPS1
Reference Standard AEC-Q101
Number of Elements 1
Element Configuration Single
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 35μA @ 40V
Voltage - Forward (Vf) (Max) @ If 500mV @ 1A
Forward Current 1A
Max Reverse Leakage Current 10mA
Operating Temperature - Junction -40°C~150°C
Max Surge Current 60A
Output Current-Max 1A
Application POWER
Forward Voltage 420mV
Max Reverse Voltage (DC) 40V
Average Rectified Current 1A
Number of Phases 1
Peak Reverse Current 35μA
Max Repetitive Reverse Voltage (Vrrm) 40V
Peak Non-Repetitive Surge Current 60A
Max Forward Surge Current (Ifsm) 60A
Dimensions
Height 2.45mm
Length 4.6mm
Width 3.95mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
