STPS1L30M
RoHS
RoHS compliant
RoHS compliantPackage DO-216AA
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 30V 1A STMITE
PDF
/
Buying Options
Total Price: USD $0.38
Unit Price: USD $0.3784
≥1 USD $0.3784
≥10 USD $0.26752
≥100 USD $0.134816
≥500 USD $0.119469
≥1000 USD $0.092972
≥3000 USD $0.083213
Inventory: 1864
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case DO-216AA
Number of Pins 2
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 1
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Max Operating Temperature 150°C
Min Operating Temperature -65°C
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Voltage - Rated DC 30V
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Current Rating 1A
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number STPS1
Pin Count 2
JESD-30 Code S-PSSO-G1
Number of Elements 1
Polarity Standard
Element Configuration Single
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 390μA @ 30V
Output Current 1A
Voltage - Forward (Vf) (Max) @ If 390mV @ 1A
Case Connection CATHODE
Forward Current 1A
Max Reverse Leakage Current 390μA
Operating Temperature - Junction 150°C Max
Max Surge Current 50A
Forward Voltage 530mV
Max Reverse Voltage (DC) 30V
Average Rectified Current 1A
Peak Reverse Current 390μA
Max Repetitive Reverse Voltage (Vrrm) 30V
Peak Non-Repetitive Surge Current 50A
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
