STPS10M60SF
RoHS
RoHS compliant
RoHS compliantPackage TO-277, 3-PowerDFN
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
60V POWER SCHOTTKY RECTIFIER
PDF
/
Buying Options
Total Price: USD $0.51
Unit Price: USD $0.5104
≥1 USD $0.5104
≥10 USD $0.43912
≥100 USD $0.303776
≥500 USD $0.25381
≥1000 USD $0.216014
≥3000 USD $0.192386
Inventory: 1356
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Surface Mount
Package / Case TO-277, 3-PowerDFN
Surface Mount YES
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
Series ECOPACK?2
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Technology AVALANCHE
Terminal Position DUAL
Terminal Form FLAT
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number STPS10
JESD-30 Code R-PDSO-F3
Operating Temperature (Max) 175°C
Number of Elements 1
Configuration SINGLE
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 50μA @ 60V
Voltage - Forward (Vf) (Max) @ If 650mV @ 10A
Case Connection CATHODE
Operating Temperature - Junction -40°C~175°C
Voltage - DC Reverse (Vr) (Max) 60V
Current - Average Rectified (Io) 10A
Number of Phases 1
Rep Pk Reverse Voltage-Max 60V
JEDEC-95 Code TO-277A
Non-rep Pk Forward Current-Max 230A
Reverse Current-Max 50μA
Compliance
RoHS Status RoHS Compliant
