STPS0560Z
RoHS
RoHS compliant
RoHS compliantPackage SOD-123
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 60V 500MA SOD123
PDF
/
Buying Options
Total Price: USD $0.3
Unit Price: USD $0.2992
≥1 USD $0.2992
≥10 USD $0.21032
≥100 USD $0.10604
≥500 USD $0.086522
≥1000 USD $0.064187
Inventory: 31123
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SOD-123
Number of Pins 2
Weight 4.535924g
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Max Operating Temperature 150°C
Min Operating Temperature -65°C
Additional Feature FREE WHEELING DIODE
Subcategory Rectifier Diodes
Voltage - Rated DC 60V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Current Rating 500mA
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number STPS0560
Pin Count 2
Number of Elements 1
Polarity Standard
Element Configuration Single
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 50μA @ 60V
Output Current 500mA
Voltage - Forward (Vf) (Max) @ If 530mV @ 500mA
Forward Current 500mA
Max Reverse Leakage Current 50μA
Operating Temperature - Junction 150°C Max
Max Surge Current 5.5A
Forward Voltage 530mV
Max Reverse Voltage (DC) 60V
Average Rectified Current 500mA
Peak Reverse Current 50μA
Max Repetitive Reverse Voltage (Vrrm) 60V
Peak Non-Repetitive Surge Current 5.5A
Max Forward Surge Current (Ifsm) 5.5A
Dimensions
Height 1.35mm
Length 2.85mm
Width 1.7mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
