STPS0520Z
RoHS
RoHS compliant
RoHS compliantPackage SOD-123
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 20V 500MA SOD123
PDF
/
Buying Options
Total Price: USD $0.32
Unit Price: USD $0.3168
≥1 USD $0.3168
≥10 USD $0.2156
≥100 USD $0.10516
≥500 USD $0.087754
≥1000 USD $0.060966
Inventory: 111013
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 1.7mm
Length 2.85mm
Height 1.45mm
Technical
Max Junction Temperature (Tj) 125°C
Max Forward Surge Current (Ifsm) 5.5A
Peak Non-Repetitive Surge Current 5.5A
Max Repetitive Reverse Voltage (Vrrm) 20V
Peak Reverse Current 150μA
Average Rectified Current 500mA
Max Reverse Voltage (DC) 20V
Forward Voltage 320mV
Max Surge Current 5.5A
Operating Temperature - Junction 125°C Max
Max Reverse Leakage Current 150μA
Forward Current 500mA
Voltage - Forward (Vf) (Max) @ If 385mV @ 500mA
Output Current 500mA
Current - Reverse Leakage @ Vr 150μA @ 20V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Single
Polarity Standard
Number of Elements 1
Base Part Number STPS0520
Current Rating 500mA
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Rated DC 20V
Subcategory Rectifier Diodes
HTS Code 8541.10.00.70
Additional Feature EXTREME FAST SWITCHING, FREE WHEELING
Min Operating Temperature -65°C
Max Operating Temperature 125°C
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Weight 4.535924g
Number of Pins 2
Package / Case SOD-123
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 15 Weeks
