FERD40H100SG-TR
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE RECT 100V 40A D2PAK
PDF
/
Buying Options
Total Price: USD $1.36
Unit Price: USD $1.3552
≥1 USD $1.3552
≥10 USD $1.1264
≥100 USD $0.89672
≥500 USD $0.758771
Inventory: 72165
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Technical
Max Forward Surge Current (Ifsm) 440A
Reverse Current-Max 190μA
Max Repetitive Reverse Voltage (Vrrm) 100V
Number of Phases 1
Average Rectified Current 40A
Max Reverse Voltage (DC) 100V
Forward Voltage 675mV
Application EFFICIENCY
Operating Temperature - Junction 175°C Max
Forward Current 40A
Case Connection CATHODE
Voltage - Forward (Vf) (Max) @ If 705mV @ 40A
Current - Reverse Leakage @ Vr 190μA @ 100V
Diode Type FERD (Field Effect Rectifier Diode)
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Single
Number of Elements 1
JESD-30 Code R-PSSO-G2
Base Part Number FERD40
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Max Operating Temperature 175°C
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Number of Pins 3
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 15 Weeks
