FERD20S100STS
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE RECT 100V 20A TO220AB
PDF
/
Buying Options
Total Price: USD $0.83
Unit Price: USD $0.8272
≥1 USD $0.8272
≥10 USD $0.71896
≥100 USD $0.497728
≥500 USD $0.415906
≥1000 USD $0.353954
≥3000 USD $0.315242
Inventory: 1256
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mounting Type Through Hole
Package / Case TO-220-3
Surface Mount NO
Diode Element Material SILICON
Technical
Packaging Tube
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number FERD20
JESD-30 Code R-PSFM-T3
Operating Temperature (Max) 175°C
Number of Elements 1
Configuration SINGLE
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type FERD (Field Effect Rectifier Diode)
Current - Reverse Leakage @ Vr 100μA @ 100V
Voltage - Forward (Vf) (Max) @ If 780mV @ 10A
Case Connection CATHODE
Forward Current 20A
Operating Temperature - Junction 175°C Max
Application EFFICIENCY
Voltage - DC Reverse (Vr) (Max) 100V
Number of Phases 1
Rep Pk Reverse Voltage-Max 100V
JEDEC-95 Code TO-220AB
Reverse Current-Max 110μA
Compliance
RoHS Status ROHS3 Compliant
