BYW98-200RL
RoHS
RoHS compliant
RoHS compliantPackage DO-201AD, Axial
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GEN PURP 200V 3A DO201AD
PDF
/
Buying Options
Total Price: USD $0.15
Unit Price: USD $0.14915
≥1 USD $0.14915
≥10 USD $0.12255
≥100 USD $0.11875
≥500 USD $0.11495
≥1000 USD $0.11115
Inventory: 63409
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case DO-201AD, Axial
Number of Pins 2
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 150°C
Min Operating Temperature -65°C
Additional Feature FREE WHEELING DIODE
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Voltage - Rated DC 200V
Terminal Form WIRE
Current Rating 3A
Base Part Number BYW98
Pin Count 2
Number of Elements 1
Voltage 200V
Element Configuration Single
Speed Fast Recovery =< 500ns, > 200mA (Io)
Current 3A
Diode Type Standard
Current - Reverse Leakage @ Vr 10μA @ 200V
Voltage - Forward (Vf) (Max) @ If 1.2V @ 9A
Case Connection ISOLATED
Forward Current 3A
Operating Temperature - Junction 150°C Max
Max Surge Current 70A
Application EFFICIENCY
Forward Voltage 850mV
Max Reverse Voltage (DC) 200V
Average Rectified Current 3A
Number of Phases 1
Reverse Recovery Time 35 ns
Peak Reverse Current 10μA
Max Repetitive Reverse Voltage (Vrrm) 200V
Peak Non-Repetitive Surge Current 70A
Reverse Voltage 200V
Recovery Time 35 ns
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
