BYT12P-1000
RoHS
RoHS compliant
RoHS compliantPackage TO-220-2
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GEN PURP 1KV 12A TO220AC
PDF
/
Inventory: 3721
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Recovery Time 155 ns
Reverse Voltage 1kV
Peak Non-Repetitive Surge Current 75A
Peak Reverse Current 50μA
Reverse Recovery Time 155 ns
Number of Phases 1
Average Rectified Current 12A
Max Reverse Voltage (DC) 1kV
Forward Voltage 1.9V
Voltage - DC Reverse (Vr) (Max) 1000V
Max Surge Current 75A
Operating Temperature - Junction -40°C~150°C
Case Connection CATHODE
Voltage - Forward (Vf) (Max) @ If 1.9V @ 12A
Power Dissipation 25W
Current - Reverse Leakage @ Vr 50μA @ 1000V
Diode Type Standard
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Single
Number of Elements 1
Qualification Status Not Qualified
Pin Count 3
Base Part Number BYT12
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Current Rating 12A
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) NOT SPECIFIED
Voltage - Rated DC 1kV
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Additional Feature FREE WHEELING DIODE
Min Operating Temperature -40°C
Max Operating Temperature 150°C
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Packaging Tube
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case TO-220-2
Mounting Type Through Hole
Mount Through Hole
