BAT60JFILM
RoHS
RoHS compliant
RoHS compliantPackage SC-76, SOD-323
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 10V 3A SOD323
PDF
/
Buying Options
Total Price: USD $0.21
Unit Price: USD $0.2112
≥1 USD $0.2112
≥10 USD $0.15048
≥100 USD $0.075944
≥500 USD $0.061987
≥1000 USD $0.045989
Inventory: 182137
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 1.45mm
Length 1.8mm
Height 1.17mm
Technical
Max Junction Temperature (Tj) 150°C
Max Forward Surge Current (Ifsm) 5A
Peak Non-Repetitive Surge Current 5A
Max Repetitive Reverse Voltage (Vrrm) 10V
Peak Reverse Current 7.5μA
Number of Phases 1
Average Rectified Current 3A
Max Reverse Voltage (DC) 10V
Forward Voltage 580mV
Current - Average Rectified (Io) 3A DC
Application GENERAL PURPOSE
Max Surge Current 5A
Operating Temperature - Junction 150°C Max
Max Reverse Leakage Current 7.5μA
Forward Current 3A
Voltage - Forward (Vf) (Max) @ If 580mV @ 1A
Output Current 3A
Current - Reverse Leakage @ Vr 6μA @ 10V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Single
Power Dissipation-Max 0.31W
Polarity Standard
Number of Elements 1
Pin Count 2
Base Part Number BAT60
Time@Peak Reflow Temperature-Max (s) 30
Current Rating 3A
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Rated DC 10V
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Min Operating Temperature -65°C
Max Operating Temperature 150°C
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Weight 4.535924g
Number of Pins 2
Package / Case SC-76, SOD-323
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 15 Weeks
Alternative Model
