BAT54WFILMY
RoHS
RoHS compliant
RoHS compliantPackage SC-70, SOT-323
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 40V 300MA SOT323
PDF
/
Buying Options
Total Price: USD $0.35
Unit Price: USD $0.352
≥1 USD $0.352
≥10 USD $0.24552
≥100 USD $0.123992
≥500 USD $0.101112
≥1000 USD $0.07502
Inventory: 1711
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Reverse Current-Max 1μA
Peak Non-Repetitive Surge Current 1A
Capacitance @ Vr, F 10pF @ 1V 1MHz
Max Repetitive Reverse Voltage (Vrrm) 40V
Reverse Recovery Time 5 ns
Number of Phases 1
Average Rectified Current 300mA
Max Reverse Voltage (DC) 40V
Forward Voltage 900mV
Current - Average Rectified (Io) 300mA DC
Operating Temperature - Junction -40°C~150°C
Forward Current 300mA
Voltage - Forward (Vf) (Max) @ If 900mV @ 100mA
Current - Reverse Leakage @ Vr 1μA @ 30V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Single
Number of Elements 1
Reference Standard AEC-Q101
Base Part Number BAT54
Terminal Form GULL WING
Terminal Position DUAL
HTS Code 8541.10.00.70
Min Operating Temperature -40°C
Max Operating Temperature 150°C
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
JESD-609 Code e3
Series Q Automotive
Packaging Cut Tape (CT)
Physical
Diode Element Material SILICON
Number of Pins 3
Package / Case SC-70, SOT-323
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
