BAT41
RoHS
RoHS compliant
RoHS compliantPackage DO-204AH, DO-35, Axial
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 100V 100MA DO35
PDF
/
Buying Options
Total Price: USD $0.22
Unit Price: USD $0.22
≥1 USD $0.22
≥10 USD $0.1496
≥100 USD $0.073128
≥500 USD $0.061002
≥1000 USD $0.042381
≥3000 USD $0.036731
Inventory: 1216
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 2mm
Length 4.5mm
Height 2mm
Technical
Max Forward Surge Current (Ifsm) 750mA
Peak Non-Repetitive Surge Current 750mA
Capacitance @ Vr, F 2pF @ 1V 1MHz
Max Repetitive Reverse Voltage (Vrrm) 100V
Peak Reverse Current 100nA
Average Rectified Current 100mA
Max Reverse Voltage (DC) 100V
Forward Voltage 400mV
Current - Average Rectified (Io) 100mA DC
Max Surge Current 750mA
Operating Temperature - Junction -65°C~125°C
Max Reverse Leakage Current 100nA
Forward Current 100mA
Case Connection ISOLATED
Voltage - Forward (Vf) (Max) @ If 450mV @ 1mA
Output Current 100mA
Current - Reverse Leakage @ Vr 100nA @ 50V
Diode Type Schottky
Speed Small Signal =< 200mA (Io), Any Speed
Element Configuration Single
Power Dissipation-Max 0.1W
Polarity Standard
Number of Elements 1
Pin Count 2
Base Part Number BAT41
Current Rating 100mA
Terminal Form WIRE
Voltage - Rated DC 100V
Subcategory Rectifier Diodes
Capacitance 2pF
HTS Code 8541.10.00.70
Additional Feature FAST SWITCHING
Min Operating Temperature -65°C
Max Operating Temperature 125°C
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Weight 4.535924g
Number of Pins 2
Package / Case DO-204AH, DO-35, Axial
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 15 Weeks
