BAT30JFILM
RoHS
RoHS compliant
RoHS compliantPackage SC-76, SOD-323
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 30V 300MA SOD323
PDF
/
Buying Options
Total Price: USD $0.27
Unit Price: USD $0.26885
≥1 USD $0.26885
≥500 USD $0.2204
≥1000 USD $0.21375
≥2000 USD $0.2071
≥5000 USD $0.20045
≥10000 USD $0.17955
Inventory: 1177
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Technical
Max Forward Surge Current (Ifsm) 1A
Peak Non-Repetitive Surge Current 1A
Capacitance @ Vr, F 22pF @ 0V 1MHz
Max Repetitive Reverse Voltage (Vrrm) 30V
Peak Reverse Current 5μA
Average Rectified Current 300mA
Max Reverse Voltage (DC) 30V
Forward Voltage 580mV
Current - Average Rectified (Io) 300mA DC
Max Surge Current 1A
Operating Temperature - Junction 150°C Max
Max Reverse Leakage Current 5μA
Forward Current 300mA
Voltage - Forward (Vf) (Max) @ If 530mV @ 300mA
Output Current 300mA
Current - Reverse Leakage @ Vr 5μA @ 30V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Single
Polarity Standard
Number of Elements 1
Qualification Status Not Qualified
Pin Count 2
Base Part Number BAT30
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Current Rating 300mA
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Rated DC 30V
Subcategory Rectifier Diodes
Capacitance 22pF
HTS Code 8541.10.00.70
Min Operating Temperature -65°C
Max Operating Temperature 150°C
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case SC-76, SOD-323
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
