BAS70ZFILM
RoHS
RoHS compliant
RoHS compliantPackage SOD-123
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 70V 70MA SOD123
PDF
/
Inventory: 2353
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Peak Non-Repetitive Surge Current 1A
Capacitance @ Vr, F 2pF @ 0V 1MHz
Max Repetitive Reverse Voltage (Vrrm) 70V
Peak Reverse Current 10μA
Average Rectified Current 70mA
Max Reverse Voltage (DC) 70V
Forward Voltage 1V
Current - Average Rectified (Io) 70mA DC
Max Surge Current 1A
Operating Temperature - Junction 150°C Max
Max Reverse Leakage Current 10μA
Forward Current 70mA
Voltage - Forward (Vf) (Max) @ If 1V @ 15mA
Output Current 70mA
Current - Reverse Leakage @ Vr 10μA @ 70V
Diode Type Schottky
Speed Small Signal =< 200mA (Io), Any Speed
Element Configuration Single
Polarity Standard
Number of Elements 1
Pin Count 2
Base Part Number BAS70
Current Rating 70mA
Peak Reflow Temperature (Cel) 225
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Rated DC 70V
Subcategory Rectifier Diodes
HTS Code 8541.10.00.70
Min Operating Temperature -65°C
Max Operating Temperature 150°C
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Packaging Tape & Reel (TR)
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case SOD-123
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
