JAN1N5806US
RoHS
/
Package /
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
RECTIFIER DIODE SINGLE MIL-19500/477F EAR99 Diode RECTIFIER DIODE 35A 0.025mus 0.875V 175C
PDF
/
Inventory: 3968
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Surface Mount YES
Diode Element Material SILICON
Technical
Part Status Active
Number of Terminations 2
ECCN Code EAR99
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Terminal Position END
Terminal Form WRAP AROUND
Reach Compliance Code unknown
Base Part Number 1N5806
Reference Standard MIL-19500/477F
JESD-30 Code O-LELF-R2
Qualification Status Qualified
Operating Temperature (Max) 175°C
Number of Elements 1
Configuration SINGLE
Diode Type RECTIFIER DIODE
Case Connection ISOLATED
Output Current-Max 2.5A
Application ULTRA FAST RECOVERY POWER
Number of Phases 1
Rep Pk Reverse Voltage-Max 150V
Non-rep Pk Forward Current-Max 35A
Forward Voltage-Max 0.875V
Reverse Recovery Time-Max 0.025μs
Compliance
RoHS Status Non-RoHS Compliant
