RF101A2ST-32
RoHS
RoHS compliant
RoHS compliantPackage DO-41 Mini, Axial
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GEN PURP 200V 1A MSR
PDF
/
Buying Options
Total Price: USD $0.12
Unit Price: USD $0.1216
≥1 USD $0.1216
≥10 USD $0.09975
≥100 USD $0.0969
≥500 USD $0.0931
≥1000 USD $0.09025
Inventory: 35009
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case DO-41 Mini, Axial
Number of Pins 2
Technical
Packaging Tape & Box (TB)
Published 2007
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Max Operating Temperature 150°C
Min Operating Temperature -55°C
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Number of Elements 1
Element Configuration Single
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 10μA @ 200V
Voltage - Forward (Vf) (Max) @ If 870mV @ 1A
Forward Current 1A
Operating Temperature - Junction 150°C Max
Max Surge Current 20A
Output Current-Max 1A
Max Reverse Voltage (DC) 200V
Average Rectified Current 1A
Reverse Recovery Time 25 ns
Peak Reverse Current 10μA
Max Repetitive Reverse Voltage (Vrrm) 200V
Peak Non-Repetitive Surge Current 20A
Reverse Voltage 200V
Recovery Time 25 ns
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
