MA2ZD1400L
RoHS
/
Package SC-90, SOD-323F
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY 20V 100MA SMINI2
PDF
/
Buying Options
Total Price: USD $0.05
Unit Price: USD $0.05415
≥1 USD $0.05415
≥10 USD $0.04465
≥100 USD $0.04275
≥500 USD $0.0418
≥1000 USD $0.04085
Inventory: 360007
Minimum: 1
-
+
Technical Details
Technical
Operating Temperature - Junction 125°C Max
Voltage - DC Reverse (Vr) (Max) 20V
Current - Average Rectified (Io) 100mA
Max Reverse Voltage (DC) 20V
Average Rectified Current 100mA
Reverse Recovery Time 3 ns
Capacitance @ Vr, F 25pF @ 0V 1MHz
Voltage - Forward (Vf) (Max) @ If 400mV @ 100mA
Output Current 100mA
Current - Reverse Leakage @ Vr 20μA @ 10V
Diode Type Schottky
Speed Small Signal =< 200mA (Io), Any Speed
Polarity Standard
Base Part Number MA2ZD14
Current Rating 100mA
Voltage - Rated DC 20V
Capacitance 25pF
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 2004
Packaging Tape & Reel (TR)
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
Physical
Supplier Device Package SMini2-F1
Package / Case SC-90, SOD-323F
Mounting Type Surface Mount
Mount Surface Mount
