DB2S20900L
RoHS
RoHS compliant
RoHS compliantPackage SC-79, SOD-523
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
Schottky Diodes & Rectifiers Schottky Diode SC-79/SOD-523
PDF
/
Inventory: 2633
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SC-79, SOD-523
Number of Pins 2
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
HTS Code 8541.10.00.60
Terminal Position DUAL
Terminal Form FLAT
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 2
Number of Elements 1
Element Configuration Single
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 30μA @ 10V
Voltage - Forward (Vf) (Max) @ If 510mV @ 500mA
Forward Current 500mA
Operating Temperature - Junction 125°C Max
Forward Voltage 510mV
Max Reverse Voltage (DC) 20V
Average Rectified Current 500mA
Reverse Recovery Time 2.4 ns
Peak Reverse Current 30μA
Max Repetitive Reverse Voltage (Vrrm) 20V
Capacitance @ Vr, F 7pF @ 10V 1MHz
Max Forward Surge Current (Ifsm) 1A
Frequency Band ULTRA HIGH FREQUENCY
Compliance
RoHS Status RoHS Compliant
