DB2J40600L
RoHS
RoHS compliant
RoHS compliantPackage SC-90, SOD-323F
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
Schottky Diodes & Rectifiers Schottky Diode SC-90A
PDF
/
Buying Options
Total Price: USD $0.68
Unit Price: USD $0.67735
≥1 USD $0.67735
≥10 USD $0.55575
≥100 USD $0.53865
≥500 USD $0.52155
≥1000 USD $0.5035
Inventory: 1099
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SC-90, SOD-323F
Number of Pins 2
Diode Element Material SILICON
Technical
Packaging Tape & Reel (TR)
Published 2014
Pbfree Code yes
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
HTS Code 8541.10.00.60
Terminal Position DUAL
Terminal Form FLAT
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 2
Number of Elements 1
Element Configuration Single
Speed Small Signal =< 200mA (Io), Any Speed
Diode Type Schottky
Current - Reverse Leakage @ Vr 5μA @ 40V
Voltage - Forward (Vf) (Max) @ If 600mV @ 100mA
Forward Current 100mA
Operating Temperature - Junction 125°C Max
Forward Voltage 600mV
Max Reverse Voltage (DC) 40V
Average Rectified Current 100mA
Reverse Recovery Time 900 ps
Peak Reverse Current 5μA
Max Repetitive Reverse Voltage (Vrrm) 40V
Capacitance @ Vr, F 2.2pF @ 10V 1MHz
Peak Non-Repetitive Surge Current 1A
Max Forward Surge Current (Ifsm) 1A
Frequency Band VERY HIGH FREQUENCY
Compliance
RoHS Status RoHS Compliant
